8×40 Screw Upgrade

$100.00

Action specs *

Menu
  • Products
    • Core Rifle Components
      • Complete Builds
      • Actions
      • Barrels
      • Triggers
      • Stocks and Chassis
      • Optics
      • Scope Mounts and Rings
    • Parts and Accessories
      • Muzzle Devices
      • ARCA Rails and Accessories
      • Bipods and Rails
      • Magazines and Extensions
      • Tools and Electronics
      • Gunsmithing & Misc
      • Shooting Bags and Range Gear
    • Reloading Gear
      • Funnel Kits
      • Auto Trickler Accessories
      • Reloading Trays
      • Die Blocks
    • Services
      • Action Services
      • Barrel Work
      • Bolt Upgrades
      • Apparel and Merchandise
        • Hats and Shirts
        • Patches and Stickers
        • Drinkware
  • Area 419 Exclusives
    • The Maverick
    • The Hellfire
    • ARCA Lock
    • The RailChanger System
    • Special Financing Packages
    • Master Funnel Kit
    • Performance Packages
  • Brands
    • –
      • Accuracy International
      • Accurate Mag
      • American Rifle Company
      • Area 419
      • Armageddon Gear
      • B&T Industries
      • Bartlein
      • Bix’n Andy
      • Cole-Tac
      • Curtis Custom
    • –
      • Defiance Machine
      • Harris Engineering
      • Hawk Hill
      • Kahles
      • Magnetospeed
      • Manners Composite Stocks
      • Tenebraex
      • Timney Triggers
      • TriggerTech
Featured Products
  • Performance Package for Bergara Rifles $305.00 $275.00
  • TriggerTech Diamond Triggers $270.00 – $310.00
  • Description
  • Additional information
  • Reviews (0)

**PLEASE FILL OUT YOUR SERVICE ORDER FORM (Download link available at purchase confirmation screen and in confirmation email) AND INCLUDE IT WITH PARTS WHEN SENT TO AREA 419**

Area 419’s 8×40 scope base screw upgrade ensures your scope is aligned perfectly with your bolt/barrel and is performed on our HAAS 4 Axis VMC.

  • Action is probed using the incredibly accurate Renishaw probing system.  The probe measures the face of the action for the zero point, then measures the angle of the truing rod placed in the bolt raceway.  This removes all user error from this process, as the entire coordinate system of the CNC gets rotated to match the truing rod, guaranteeing the screw holes are all parallel with the raceway.
  • Holes are circular interpolated with an 1/8″ carbide endmill.  Drilling holes is not sufficient, as a drill operation will follow the path of least resistance, even when using an endmill as the drill.
  • 8×40 Threads are thread milled into the receiver.  Again, tapping will follow the path of least resistance and not guarantee everything is where it should be.
  • Available on Remington 700 Short and Long action

Weight 4 lbs
Dimensions 8 × 3 × 3 in

Reviews

There are no reviews yet.
